YSH Series 1" Clear PVC Y-Strainer — Integral Threaded Ends, FPM (Viton®) Seal
Hayward YSH 1" Clear PVC Y-Strainer with Integral Threaded Ends
This 1" Hayward YSH Series Y-Strainer combines reliable particulate removal with a compact, serviceable design built for commercial and industrial filtration systems. The body is molded from Clear PVC (Clear PVC Cell Class 12454 per ASTM D1784), paired with a PVC straining basket and FPM (Viton®) o-ring seals.
The transparent Clear PVC construction allows operators to visually monitor flow conditions and screen buildup without disassembly, reducing downtime during maintenance checks.
Integral threaded ends allow for straightforward installation and removal using standard NPT fittings, making this a practical choice for applications that may require periodic repositioning.
Sealed with FPM (Viton®) o-rings for superior resistance to fuels, oils, solvents, and concentrated chemicals — the preferred option for aggressive chemical handling applications.
Specifications
| Pipe Size | 1" |
| Body Material | Clear PVC |
| Screen/Basket Material | PVC |
| End Connections | Integral Threaded |
| Seal Material | FPM (Viton®) |
| Cv (Flow Coefficient) | 9.0 |
| Max Pressure | 150 PSI @ 70°F |
| Screen Perforation Options | 1/16", 1/32", 1/8", 3/16" |
Design Highlights
The YSH Series features exterior buttress threads and a pressure-relieving chamfered barrel nut for safer servicing. An optional hex cap provides tool-assisted screen access, while pre-drilled cap taps accommodate blow-out or gauge ports. Clear PVC screen inserts are available for visual monitoring. Suitable for horizontal or vertical mounting. Optional mesh screens (20–325 mesh) offered in stainless steel, PVDF, Hastelloy, titanium, and Monel for specialized filtration needs.
